CMOS-740HDHD Rear Camera

Buy Now

High Definition View

Displaying the image in true 1280 x 720 (720P) High Definition on compatible DNR1007XR, DNR1008RVS, DMX1057XR, DMX1037S, DNX997XR, DDX9907XR, and DMX958XR receivers.

WVGA Camera

HD Camera

HDR (High Dynamic Range)

— Reducing “Blown out Highlights” and “Crushed Blacks” —
HDR helps to reduce “blown out highlights” and “crushed blacks” and ensure clear images in challenging environments, including backlit scenes in daylight, streetlight scenes at night and places where light-dark contrast is particularly severe.



12V & 24V Compatible

Cameras work with both 12V and 24V applications.

General Features

Photographed Image HD (1280 x 720)
Lens Wide angle, focal length: 1.86mm F:2.0
Frame Rate 30fps
Angles of View Horizontal 180°/ Vertical 103°
Operating Voltage 12V/24V
Operating Temperature -22℉ to +185℉ / -30℃ to +85℃
Output HD-TVI
Weight 0.073lbs / 33.2g (without cable)
Dimensions (W x H x D) 1-1/4" x 15/16" x 1" / 31.1mm x23.0mm x25.2mm
Cable Length
Camera Unit side 9.84ft / 3m
DC Box Unit side 19.69ft / 6m
Other 1.64ft / 0.5m
