2-CHANNEL POWER AMPLIFIER, 6X9" SPEAKERS, & LID KIT PACKAGE DESIGNED AND ENGINEERED TO BE PLUG AND PLAY FOR SELECT 1998-2013 HARLEY-DAVIDSON® MOTORCYCLES
Products Included In Package
- Qty: 1 XM160-2-98
- Qty: 1 XM69R
- Qty: 1 CA-LID98
- Qty: 1 CA-PLT98
XM160-2-98
- Class D 2-Channel Power Amplifier
- 80W x 2 @ 2 ohms (RMS)
- No Radio Flash Required
- Bypass Port For System Expansion
- Plug & Play Power, Speaker, & Input Wiring
- Speaker Level Input For HD OEM Radio or Any Aftermarket Receiver
- Input Sensitivity Adjustment
- High Efficiency Design Will Not Overload HD Electrical Systems
XM69R
- IMPP Woofer Cones
- 1” (PEI) Dome Tweeters
- Street Glide® Metal Mesh Grilles Included
- Impedance: 2 Ohm
- Mounting Depth: 2.25”
- Sensitivity: 92dB
- Frequency Response: 40Hz-25kHz
- RMS Power Handling: 150W
- Peak Power Handling: 300W
CA-LID98
- Primed And Ready For Paint
- Injection Molded Using High Impact ABS
- Optimal Speaker Positioning Faces Rider
- Minimal Loss Of Bag Space
- Built-in Water Drain Channels
CA-PLT98
- Amplifier Side Mounting Plate for 2nd XM160-2-98 Amplifier
*The CA-PLT98 will only be required if a second amplifier is being installed in the bike, however, it may also be used to hold a single amplifier if preferred or if there is not space on top of the radio.
2-Year Warranty for P-HD2RSG-98 Package.
