Amplifier

KAC-PS704EX

AB-Class, 70W x 4ch
Hi-Performance Amplifier

KAC-PS704EX KAC-PS704EX
(1)
(2)
(3)

(1) A better cooling system with fan

(2) 45mm large toroidal transformer,
Secondary Capacitor 9900uF and Primary Capacitor 6600uF ensure solid performance

(3) One-side Terminals for Easier Installation
Speaker-level Input with Signal Sensing Turn-On

Amplifier Tech-Spec KAC-PS704EX
Maximum Output Power 1000W
RMS Power at 4ohms 70W x 4ch
RMS Power at 2ohms 100W x 4ch
Bridged at 4ohms 200W x 2ch
Frequency Response 20Hz - 50kHz
High Pass Filter 80Hz, -12dB/oct
Low Pass Filter 50Hz – 200Hz, -24dB/oct
Speaker Level Input Yes
Signal to Noise Ratio 100dB
Dimensions W x D x H (mm) 335 x 204 x 56

KAC-PS917D

Class D Mono

KAC-PS917D
Amplifier Tech-Spec KAC-PS917D
Maximum Output Power 2000W
RMS Power at 4ohms 500W
RMS Power at 2ohms 1000W
Bridged at 4ohms
Frequency Response 20Hz - 200Hz
High Pass Filter
Low Pass Filter 50Hz - 200Hz, -24dB/oct
Speaker Level Input Yes
Signal to Noise Ratio 100dB
Dimensions W x D x H (mm) 335 x 192 x 56

KAC-PS947

4/3/2 Channel Power Amplifier

KAC-PS947
Maximum Output Power 2000W
RMS Power at 4ohms 70W x 4 ( 20 Hz- 20kHz, ≤ 1.0 % THD)
RMS Power at 2ohms 100W x 4 (1kHz, ≤ 1.0 % THD)
Bridged at 4ohms 200W x 2 (1kHz, ≤ 1.0 % THD)
Frequency Response 20Hz - 50kHz
High Pass Filter 50Hz – 200Hz (-12 dB/oct.)
Low Pass Filter 50Hz – 200 Hz (-12 dB/oct.)
Speaker Level Input Yes
Signal to Noise Ratio 100dB
Dimensions W x D x H (mm) 335 x 56 x 192
Weight 2.6kg

Speaker

KFC-PS170C

17cm Component Speaker

KFC-PS170C KFC-PS170C
(1)
(2)
(3)
(4)

(1) 170mm Wide Etched PP Woofer Cone creates solid bass sound by avoiding deformation of diaphragm

(2) Convex Shape PP+Mica+Carbon Cap enhances mid-range performance.

(3) Audiophile grade External Network Box
using hi-quality crossover film capacitors and inductors Tweeter High Pass Filter : -12dB/oct.

(4) Swivel Type 25mm soft dome Tweeter Able to adjust the direction after installation

Speaker Tech-Spec KFC-PS170C
Peak Input Power 400W
RMS Input Power 80W
Size 17cm
Tweeter Design Soft Dome
Tweeter Magnet Composition Neodymium
Woofer Magnet Composition Ferrite
Nominal Impedance 4ohms
Frequency Response 58Hz - 22kHz
Sensitivity (dB/W at 1m) 86dB
Mounting Depth 56mm

KFC-PS6996EX / 6996 / 6986/ 6976

6 x 9 inch 5Way / 4Way / 3Way Speaker

KFC-PS6996EX / 6986/ 6976

Diamond Array Patttern Woofer Cone

enhances sound and reduces distortion.

Sound Field Enhancer

The unique shape of the tweeter creates strong frontward sound as well as a wider sound field in 5kHz and upper frequencies.

Acoustic Sound Harmonizer

harmonizes different sounds from the woofer and tweeter and reproduces a natural sound.

Factory Location Fit

The tweeter height is designed as low as possible, and the speaker units can fit within most of the spaces for factory speakers.

1. Black-painted Woofer Yoke Plate

efficiently releases heat inside the magneticcircuit and prevents the temperature of the voice coil from rising, resulting in improved durability.

2. New Shape of Woofer Damper

minimizes mechanical stress and makes the sound response smoother.

Speaker Tech-Spec KFC-PS6996EX KFC-PS6996 KFC-PS6986 KFC-PS6976
Peak Input Power 700W 650W 600W 550W
RMS Input Power 160W 150W 140W 130W
Size 6 x 9 inch 5Way 6 x 9 inch 5Way 6 x 9 inch 4Way 6 x 9 inch 3Way
Tweeter Design Balanced Dome Balanced Dome Balanced Dome Balanced Dome
Tweeter Magnet Composition Ferrite Ferrite Ferrite Ferrite
Woofer Magnet Composition Ferrite Ferrite Ferrite Ferrite
Nominal Impedance 4ohms 4ohms 4ohms 4ohms
Frequency Response 55Hz-22kHz 58Hz–22kHz 60Hz–22kHz 63Hz–22kHz
Sensitivity (dB/W at 1m) 88dB 88dB 88dB 88dB
Mounting Depth 81.5mm 80.5mm 80.5mm 80.5mm

KFC-PS1696

16cm 2Way Speaker

KFC-PS1696
Speaker Tech-Spec KFC-PS1696
Peak Input Power 320W
RMS Input Power 100W
Size 16cm 2Way
Tweeter Design Balanced Dome
Tweeter Magnet Composition Neodynium
Woofer Magnet Composition Ferrite
Nominal Impedance 4ohms
Frequency Response 75Hz-24kHz
Sensitivity (dB/W at 1m) 88dB
Mounting Depth 48mm

Subwoofer

KFC-PS2517W

25cm Subwoofer

KFC-PS2517W

Durability Enhancement

Heat-resistant Alminum Bobbin provides higher thermal conductivity.

Stress Controlled Spider

Computer-optimized Dumper controls stress and increase mechanical durability.

Subwoofer Tech-Spec KFC-PS2517W
Peak Input Power 1300W
RMS Input Power 300W
Size 25cm
Woofer Magnet Composition Ferrite
Nominal Impedance 4ohms
Frequency Response 33Hz–300Hz
Sensitivity (dB/W at 1m) 84dB
Mounting Depth 124mm

KFC-PS2516W

25cm Subwoofer

KFC-PS2516W
Subwoofer Tech-Spec KFC-PS2516W
Peak Input Power 1300W
RMS Input Power 300W
Size 25cm
Tweeter Design
Tweeter Magnet Composition
Woofer Magnet Composition Ferrite
Nominal Impedance 4ohms
Frequency Response 32Hz–300Hz
Sensitivity (dB/W at 1m) 81dB
Mounting Depth 116.3mm
