nx-3220_3320

NX-3220/3320

Other Features

Multi-protocol digital radio: Designed to operate under NXDN® or DMR digital,
and FM analog protocols
NXDN® Conventional and Type-C & Gen2 Trunking
DMR Tier 2 Conventional & Site Roaming
DMR Auto Slot Select
DMR Tier 3 Trunking
Mixed Digital & FM Analog Operation allows gradual migration at your own pace
4-Line Basic Frame (2-Line Main/Sub-LCD, icon & key guide) / 14 Characters
5-Line Text Message Frame (3 Lines of Text, icon & key guide)
7-color Light Bar Indicator on the top panel. Individual color can be set for each channel
4-way Directional-pad (D-pad) for intuitive control and operation
Built-In GPS Receiver/Antenna for effective fleet and incident management
Built-in Bluetooth® for hands-free operation for IoT applications- Applicable Bluetooth
profiles: HSP (Headset Profile) and SPP (Serial Port Profile)
Renowned KENWOOD Audio Quality achieved with Active Noise Reduction
(ANR) that utilizes built-in DSP
Optional DES and AES Encryption
Built-in Motion Sensor (Man-down, Stationary and Motion Detection)
IP54/55/67 and MIL-STD-810 C/D/E/F/G
1 Watt Audio Output Power
UHF: 120 MHz capability
Available models: Full Keypad (w/ LCD and full keypad), Standard Keypad
(w/ LCD and 4-way large D-pad/4 key), and Basic (w/o LCD and keypad)
260 CH/128 Zones (64 CH/4 Zones for Basic model)
Maximum of 1,000 CH/Radio with option
Intrinsically Safe Option
Paging Call
Emergency Call
Status/Text Message
Remote Stun/Kill/Check
