KMM-BT205
KMM-BT205

KMM-BT205USB 收放机

  • 内置蓝牙
  • 直接蓝牙控制键
  • 红/白色照明
  • Spotify控制
  • 1 个预输出 2.5V

高级蓝牙技术

通过将智能手机和接收机进行无线连接, 可让您在驾驶时享受更多乐趣和便捷。

了解更多

了解更多

专用USB功能

USB连接适用于智能设备和兼容的USB大容量存储设备。

了解更多

了解更多

其他有用的功能

了解令人兴奋的产品功能和亮点。

了解更多

了解更多

按键照明 / LCD - LED 背光 /
内置蓝牙 双机免提 / 音乐组合 / 建伍远程应用
Spotify控制 全控制
USB端子 x 1
音频解码器 FLAC / WAV / AAC / MP3 / WMA
均衡器 / 数字时间校准 / 3向分频 13 段 / 是 / 是
音频预输出 2.5V / 1个预置输出口
遥控器 选购

建伍车载电子系统

Authorized KENWOOD Retailers

Purchase KENWOOD Products ONLY from Authorized KENWOOD Retailers! Because KENWOOD cannot guarantee that car audio product purchased from unauthorized dealers are genuine, new and/or fit for purchase, KENWOOD does NOT offer any manufacturer's limited warranty or rebates for car audio products purchased from a dealer that is not authorized by KENWOOD.

Where to Buy

« 滚动
FM Frequency Range
(Frequency step)
87.5MHz to 108.0MHz
(50kHz)
Usable Sensitivity
S/N30dB
8.2dBf
(0.71μV/75Ω)
Quieting Sensitivity
DIN S/N 46dB
17.2dBf
(2.0μV/75Ω)
Frequency Response
(±3.0dB)
30Hz to 15kHz
S/N 64.0dB(MONO)
Stereo Separation 40dB(1kHz)
AM Frequency Range
(Frequency step)
Band 1(MW) / 531kHz to 1602kHz(9kHz)
Band 2(SW1) / 2940kHz to 7735kHz(5kHz)
Band 3(SW2) / 9500kHz to 10135kHz / 11580kHz to 18135kHz (5kHz)
Channel Space Selection Band 1 / 9kHz
Band 2/3 / 5kHz
Usable Sensitivity
S/N:20dB
29.0dBμ(28.2μV):MW
30dBμ (32μV):SW
Preout Level(mV)/Load       -Unbalanced 2500mV/10kΩ(USB)
Preout Impedance(Ω) ≦600Ω
Speaker Impedance(Ω) 4 to 8Ω
USB I/F USB USB 1.1 / 2.0 Full speed
File System FAT12 / 16 / 32
Maximum Supply current DC5V(DC logo) 1.5A
Frequency Response 20Hz to 20kHz(±1dB)
S/N Ratio (dB) 99dB(1kHz)
Dynamic Range 93dB
Channel Separation 89dB
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
AAC Decode AAC-LC ".aac", ".m4a" files
WAV Decode Linear-PCM
FLAC Decode FLAC file (Up to 96kHz/24bit)
AUX
Input
Frequency Response 20Hz to 20kHz ±3dB
Input Maximum Voltage 1000mV
Input Impedance 30kΩ
AMP Maximum Power 50Wx4
Full Bandwidth Power
(at less than 1%THD)
22Wx4
TONE Band1 62.5Hz ±9dB
Band2 100Hz ±9dB
Band3 160Hz ±9dB
Band4 250Hz ±9dB
Band5 400Hz ±9dB
Band6 630Hz ±9dB
Band7 1kHz ±9dB
Band8 1.6kHz ±9dB
Band9 2.5kHz ±9dB
Band10 4kHz ±9dB
Band11 6.3kHz ±9dB
Band12 10kHz ±9dB
Band13 16kHz ±9dB
Bluetooth Version Bluetooth 3.0
Frequency Range 2.402 to 2.480GHz
RF Output Power (E.I.R.P.) +4dBm (MAX), Power Class 2
Maximum Communication range Line of sight approx.10m(32.8ft)
Profile HFP 1.6 (Hands Free Profile)
SPP (Serial Port Profile)
PBAP (Phonebook Access Profile)
A2DP (Advanced Audio Distribution Profile)
AVRCP 1.5 (Audio/Video Remote Control Profile)
GENE Operating voltage 12V DC car battery
Installation Size
(W)
(H)
(D)
182mm
53mm
100mm
Net Weight
(Trim plate and Mounting sleeve: Included)
0.6(kg)
